swirl diffuser roundA well-rounded solution. The swirl diffuser round has radially arranged air channel and diffuser openings.
available heretechnical informations
- Round swirl diffuser for supply air
- Volume flow rate range: 10–250 m³/h
- Steel sheet with electrostatic powder coating
- Radially arranged air channel openings and 480 diffuser openings
- Installation in mineral fibre or metal sheet ceilings via on-site connection box AKH 09 of the company Trox
- Please check product sizes in technical drawing
- Simple installation
- Protected design, made in Germany
material und farbe
material und farbe
ral 9016-20 traffic white
- colour
Standard colour RAL 9016-20, traffic white, layer thickness approx. 60 µ
- Material
Steel sheet with electrostatic powder coating
*Powder coating in all valid RAL Classic colours from the 840-HR and RAL 841-GL primary standards as well as special coatings are optional for an extra charge.
Swirl diffuser Round
The swirl diffuser Round with radially arranged air control blades.
- Item No1000300-9016-20
- Dimension254 mm
Details & Downloads
downloads and ressourcen
Technical data
Technical drawing
Tender specification
